BP SX 20M Solar Module

Typical Electrical Characteristics Max Power 20 watts Warranted Minimum Power 18 watts Voltage @ Max Power 16.8v Current @ Max Power 1.19A Short Circuit Current 1.29A Open Circuit Voltage 21.0V Max Series Fuse Rating 3A Max System Voltage 30v Mechanical Characteristics Dimensions (mm) 19.72 x 16.58 x 0.9 Weight (lbs) 5.5 Frame Clear anodized aluminum alloy type 6063T6 Silver mount frame. Solar Cells 36 cells configured geometrically for a 4 x 9 matrix connected in series Output Cables RHW AWG# 18 2 Core PLTC Cable. Lengths 18in.("-" black) and 18in. ("+" red) Construction Front: High Transmission 3mm tempered glass Rear: Blue tedlar: Encapsulant: EVA.

Price: $200.00
